Specification |
Frequency |
1166-1280 MHz, 1559-1610 MHz for: |
GPS |
L1 C/A, L2E, L2C, L5 |
GLONASS |
L1 C/A, L1 P, L2 C/A, L2 P |
BeiDou |
B1, B2, B3 |
SBAS |
L1 C/A and QZSS L1 |
Galileo |
E1, E5A, E5B |
Polarization |
RHCP |
Axial Ratio |
1 dB Typ. 3 dB max |
LNA |
Gain |
40 dB |
Noise Figure |
< 2.0 dB |
Port VSWR |
< 2.0 : 1 |
Voltage |
3.0 - 6.0 V DC |
Current Draw |
< 65 mA |
ESD |
8 KV |
Environment |
Operating Temperature |
-40 °C - +85 °C |
Storage Temperature |
-40 °C - +85 °C |
Humidity |
100% |
IP67 compliance |
Physical |
Dimension |
6.3"(D) x 2"(H) (161 mm diameter x 51 mm height) |
Weight |
500 g |
Radome |
ABS UV resistant painting |
Connector |
TNC-F |
Standard 5/8" survey pole mount |
